Linde H 80 D - Relay and Fuses of 353 -03 LPG

Page 38
Section 4.6
Service Training
09.04
4.6.10.2 RELAY AND FUSES OF 353 -03 LPG
1 Relay K3 for LPG cut-off
2 Relay K2 for starter
3 Relay K4 load relay
4 Indicator relay 5K1
5 Relay 9K1 for interval
6 Relay 9K2 for interval
7 Relay 9K3 for wiper
8 Relay for plus distributor
9 Fuse 70 A MTA
10 Plug connector 5X1/5X2/5X3/9X1/9X6/7X4/9X4
11 Minus distributor
