Linde H 80 D - Page 162

Page 4
Section 4.5
Service Training
BOWDEN CABLE FOR THE PARKING BRAKE
- Depress the brake pedal until the flat spring (1) engages.
- Set the lever on the control unit cover to the "Brake engaged" position.
- Remove any play in the brake cable (2) at the lower end by clamping the nipple (3).
