D9U001GE4-0101_05
11
1.9 Denitions
Basic Bed Conguration the pricelist model conguration, not including a mattress
Bed Weight The value depends on the product conguration, accessories or
customer adjustments.
Clearance of Undercarriage the height from the oor to the lowest point of the undercarriage
between the castors, for the manipulation of accessories under a
braked bed in the standard position
Duty Cycle cycle of operation of the motor: time of activity/time of rest
Ergoframe Ergoframe is the kinematic system of mattress support platform
Adjustment whose effect is the elimination of pressure on the
patient´s abdomen and pelvic area and frictional forces on the
patient‘s back and legs.
Maximum Patient Weight Maximum Patient Weight depends on the application environ-
ment according to IEC 60601-2-52. For application environment
1 (intensive/critical care) and 2 (acute care) reduce Safe working
Load by 65 kg. For application environment 3 (long-term care) and
5 (ambulatory care) reduce Safe working Load by 35 kg.
Safe Working Load the highest allowable load on the bed (patient, mattress, accesso-
ries and the load supported by those accessories)
Siderail Height the height of the upper crossbar or the edges of the siderails (not
the highest point of the siderail controls) from the patient surface
Standard Bed Position - The height of the patient surface with regard to the oor is 400
mm
- The mattress support platform, including the individual parts, has
to be in a horizontal (level - 0°) position.
- The siderails are always locked in the upper position.
- The basic position of the integrated extension.
