12 Scales Control (only version with scales)
Use iBoard Basic to control the scales.
iBoard Basic
12.1 Preparation
► Install mattress and accessories to prepare bed before patient admission and using the scales.
CAUTION!
Incorrect use of scales due to incomplete preparation!
► Before each patient admission tare the scales.
12.2 Taring
Taring can be done in a range of 5kg to 249.5kg. Taring is used to set “0” on the display before placing the patient on the bed.
Taring must be done with an unloaded bed with mattress, bed sheets, pillows and necessary accessories, without the patient. It is
recommended to position Mattress support platform about 20 cm above the lowest horizontal position.
To tare weight:
► Ensure that nothing and nobody touches the bed except you.
► Press and hold button until value (6) starts to ash. Release button .
► Press button again to conrm taring. “0” is shown on the display.
Place the patient on the bed.
To cancel taring:
► Press button
while taring.
12.3 Displaying
Verication Scale Interval is 0.5 kg.
► Press button to display value with actual scale interval 0,1 kg for 5s.
During this mode unit of weight (kg) and decimal point are ashing on the display.
Field 6 shows normally actual weight value if other functions are not activated.
NOTE Weight value automatically disappears after 1 minute. If it is needed, press button
to display it again.
Fig. Scales Section (iBoard Basic) - display and keyboard
6
5
187 2 3
4
1. ZERO/T Button (tare or zero scales)
2. WEIGHT/CLEAR Button (cancel)
3. Scale interval switch button
(0,5kg/0,1kg)
4. HOLD Button
5. Backrest Angle Indicator
6. Weight value
7. Stabilized Scales Icon
8. Unit of weight (kg)
