D9U001GE4-0101_05
69
15 Mattress
Eleganza 4 bed is designed for mattresses from LINET portfolio.
CAUTION!
Incompatibility with bed due to incorrect mattress dimensions!
► Check maximum approved mattress dimensions (chapter Technical Specication of Eleganza 4).
The manufacturer recommends the use of the following mattresses on the Eleganza 4 bed:
PASSIVE MATTRESSES ACTIVE MATTRESSES
■ CliniCare 10 ■ CliniCare 100 HF
■ CliniCare 20 ■ Air2Care
■ CliniCare 30 ■ Virtuoso
15.1 Installation of Passive Mattress
The passive mattresses intended for Eleganza 4 bed are equipped with straps with buckles (1) to x mattress on the Mattress
Support Platform.
Fig. Bottom of Passive Mattress
1
1
15.1.1 Straps with side release buckles
To x mattress on the Mattress Support Platform:
► Run three straps through the three corresponding holes in the covers of Mattress Support Platform.
► Run these three straps under the bars of the Mattress Support Platform.
► Lock the three side release buckles by connecting their male and female parts together.
To remove mattress from the Mattress Support Platform:
► Release the three buckles by pressing them from both sides and by disconnecting their male and female parts.
► Pull these three straps out of the Mattress Support Platform.
► Remove mattress from the Mattress Support Platform.
