Page E-6
MPS Motor Protection System Rev. 6-F-022117
Appendix E, Communications Database Table
MPS
REGISTER
(DECIMAL)
MODBUS
REGISTER
(DECIMAL)
A-B FILE
(DECIMAL)
(NOTE 4)
DESCRIPTION
ACCESS
RANGE
TYPE
255
Stage 3 Delay
R/W
0.1 - 500
T1(Low)
256
T1(High)
257
Backspin-Timer Enable
0 - 1
T6
258
Backspin-Time Delay
0.1 - 3,600 s
T1(Low)
259
T1(High)
Current Transfers
260
40261
3:260
Transfer Type
R/W
0 - 1
T41
261
Transfer Level
R/W
1.0 - 3.0 x FLA
T1 (Low)
262
T1 (High)
Digital Inputs
264
40265
3:264
Input 1 Function
R/W
0 - 19
T12
265
Input 1 Bypass Enable
R/W
0 - 1
T6
266
Input 1 Bypass Delay
R/W
0.5 - 100 s
T1(Low)
267
T1(High)
268
Input 1 Trip Delay
R/W
0.01 - 100 s
T1(Low)
269
T1(High)
274
Input 2 Function
R/W
0 - 19
T12
275
Input 2 Bypass Enable
R/W
0 - 1
T6
276
Input 2 Bypass Delay
R/W
0.5 - 100 s
T1(Low)
277
T1(High)
278
Input 2 Trip Delay
R/W
0.01 - 100 s
T1(Low)
279
T1(High)
284
Input 3 Function
R/W
0 - 19
T12
285
Input 3 Bypass Enable
R/W
0 - 1
T6
286
Input 3 Bypass Delay
R/W
0.5 - 100 s
T1(Low)
287
T1(High)
288
Input 3 Trip Delay
R/W
0.01 - 100 s
T1(Low)
289
T1(high)
294
Input 4 Function
R/W
0 - 19
T12
295
Input 4 Bypass Enable
R/W
0 - 1
T6
296
Input 4 Bypass Delay
R/W
0.5 - 100 s
T1(Low)
297
T1(High)
298
Input 4 Trip Delay
R/W
0.01 - 100 s
T1(Low)
299
T1(High)
304
Input 5 Function
R/W
0 - 19
T12
305
Input 5 Bypass Enable
R/W
0 - 1
T6
306
Input 5 Bypass Delay
R/W
0.5 - 100 s
T1(Low)
307
T1(High)
308
Input 5 Trip Delay
R/W
0.01 - 100 s
T1(Low)
309
T1(High)
