Page E-17
MPS Motor Protection System Rev. 6-F-022117
Appendix E, Communications Database Table
MPS
REGISTER
(DECIMAL)
MODBUS
REGISTER
(DECIMAL)
A-B FILE
(DECIMAL)
(NOTE 4)
DESCRIPTION
ACCESS
RANGE
TYPE
1033
Module 2 #7 Temperature
(9)
Read Only
T1(Low)
1034
T1(High)
1035
Module 2 #8 Temperature
(9)
Read Only
T1(Low)
1036
T1(High)
1037
Differential Current Phase A (A)
(6)
Read Only
T1(Low)
1038
T1(High)
1039
Differential Current Phase B (A)
(6)
Read Only
T1(Low)
1040
T1(High)
1041
Differential Current Phase C (A)
(6)
Read Only
T1(Low)
1042
T1(High)
1043
Reserved
Read Only
T1(Low)
1044
T1(High)
1045
Reserved
Read Only
T1(Low)
1046
T1(High)
1047
Reserved
Read Only
T1(Low)
1048
T1(High)
1049
Reserved
Read Only
T1(Low)
1050
T1(High)
1051
Reserved
Read Only
T1(Low)
1052
T1(High)
1053
Frequency
Read Only
T1(Low)
1054
T1(High)
1055
Power—S (kVA)
Read Only
T1(Low)
1056
T1(High)
1057
Power—P (kW)
Read Only
T1(Low)
1058
T1(High)
1059
Power—Q (kVAR)
Read Only
T1(Low)
1060
T1(High)
1061
Power Factor
Read Only
T1(Low)
1062
T1(High)
Underpower
1070
41071
7:97
Trip Action
R/W
0 - 7
T42
1071
Trip Level
R/W
0.1 - 1.0
T1(Low)
1072
T1(High)
1073
Trip Delay
R/W
0.5 - 500 s
T1(Low)
1074
T1(High)
1075
Alarm Level
R/W
0.1 - 1.0
T1(Low)
1076
T1(High)
1077
Alarm Delay
R/W
10.5 - 500 s
T1(Low)
1078
T1(High)
1079
Alarm Action
R/W
0 - 7
T43
Reversepower
1080
41081
7:107
Trip Action
R/W
0 - 7
T42
1081
Trip Level
R/W
0.1 - 1.0
T1(Low)
1082
T1(High)
1083
Trip Delay
R/W
0.5 - 500 s
T1(Low)
