Page E-19
MPS Motor Protection System Rev. 6-F-022117
Appendix E, Communications Database Table
MPS
REGISTER
(DECIMAL)
MODBUS
REGISTER
(DECIMAL)
A-B FILE
(DECIMAL)
(NOTE 4)
DESCRIPTION
ACCESS
RANGE
TYPE
1158
RTD Module 1 #3
Read Only
T3
1159
RTD Module 1 #4
Read Only
T3
1160
RTD Module 1 #5
Read Only
T3
1161
RTD Module 1 #6
Read Only
T3
1162
RTD Module 1 #7
Read Only
T3
1163
RTD Module 1 #8
Read Only
T3
1164
RTD Module 2 #1
Read Only
T3
1165
RTD Module 2 #2
Read Only
T3
1166
RTD Module 2 #3
Read Only
T3
1167
RTD Module 2 #4
Read Only
T3
1168
RTD Module 2 #5
Read Only
T3
1169
RTD Module 2 #6
Read Only
T3
1170
RTD Module 2 #7
Read Only
T3
1171
RTD Module 2 #8
Read Only
T3
1172
RTD Module 3 #1
Read Only
T3
1173
RTD Module 3 #2
Read Only
T3
1174
RTD Module 3 #3
Read Only
T3
1175
RTD Module 3 #4
Read Only
T3
1176
RTD Module 3 #5
Read Only
T3
1177
RTD Module 3 #6
Read Only
T3
1178
RTD Module 3 #7
Read Only
T3
1179
RTD Module 3 #8
Read Only
T3
1180
RTD Module 1 Comm
Read Only
T3
1181
RTD Module 2 Comm
Read Only
T3
1182
RTD Module 3 Comm
Read Only
T3
1183
RTD Sensor
Read Only
T3
1184
Start Time Exceeded
Read Only
T3
1185
Display Comm
Read Only
T3
1186
Stop (In Protection Only)
Read Only
T3
1187
Lagging Power Factor – Q4
Read Only
T3
1188
Underfrequency
Read Only
T3
1189
Overfrequency
Read Only
T3
1190
A/D
Read Only
T3
1191
Network
Read Only
T3
1192
Leading Power Factor – Q3
Read Only
T3
1193
Starts Per Hour
Read Only
T3
1194
Differential Module Trip
Read Only
T3
1195
Differential Current Trip
Read Only
T3
1196
Reduced Overcurrent Trip
Read Only
T3
1197
Underpower Trip
Read Only
T3
1198
Reversepower Trip
Read Only
T3
Running Time
1210
41211
9:0
Running Seconds
Read Only
T2(Low)
1211
T2(High)
Energy
1212
41213
9:2
kW Seconds
Read Only
T4(Word 1)
1213
T4(Word 2)
