Appendix F, Register Formats
TYPE
C TYPE
DESCRIPTION
T12
Short
Digital Input Function
0: Input Not Used
1: Start 1 (N.O. Contact)
2: Start 2 (N.O. Contact)
3: Stop (N.C. Contact)
4: Starter RLYA Status
5: Starter RLYB Status
6: Starter RLYC Status
7: Starter RLYD Status
8: Interlock (N.C.)
9: Trip1 (N.C.)
10: Reset (N.O.)
11: Local Select -
12: Local Start1
13: Local Start2
14: 2-Wire Start1
15: 2-Wire Start2
16: FLA2 Select
17: Limit1 Stop
18: Limit2 Stop
19: Reduced OC
20: Local Select +
T13
Short
Relay Output Function
0: None
1: Starter RLYA
2: Starter RLYB
3: Starter RLYC
4: Starter RLYD
5: Trip1
6: Alarm1
7: Trip 2
8: Interlock
9: Local
10: Current Detected
11: Run Mode
12: Starter Sequence Complete
13: Thermal Lockout/Start Inhibit
14: None
15: Watchdog
16: Trip3
17: Alarm2
18: Alarm3
19: Trip1 Pulse
20: Reduced OC
T14
Short
Relay Trip/Alarm Mode
0: Fail Safe
1: Non Fail Safe
