Page F-4
MPS Motor Protection System Rev. 6-F-022117
Appendix F, Register Formats
Register +0: Char[0] and Char[1]. Char [0] at MSByte
Register +1: Char[2] and Char[3]. Char [2] at MSByte
Register +2: Char[4] and Char[5]. Char [4] at MSByte
Register +3: Char[6] and Char[7]. Char [6] at MSByte
Register +4: Char[8] and Char[9]. Char [8] at MSByte
Register +5: Char[10] and Char[11]. Char [10] at MSByte
Register +6: Char[12] and Char[13]. Char [12] at MSByte
Register +7: Char[14] and Char[15]. Char [14] at MSByte
Register +8: Char[16] and Char[17]. Char [16] at MSByte
Register +9: Char[18] and Char[19]. Char [18] at MSByte
A character value of 0 (NULL) will terminate the string and the following characters will be
ignored.
Ethernet address strings are of the form: “ddd.ddd.ddd.ddd”.
The MAC address is a hex string of the form: “hhhhhhhhhhhh”.
Bits 31..16: Year in Binary
Bits 15..8: 1-12 Months in Binary
Bits 7..0: 1-31 days in Binary
Bits 31..24: 0-23 Hours in Binary
Bits 23..16: 0-60 Minutes in Binary
Bits 15..8: 0-60 Seconds in Binary
Bits 7..0: 0-99 Hundredths of Seconds in Binary
