Page F-9
MPS Motor Protection System Rev. 6-F-022117
Appendix F, Register Formats
TYPE
C TYPE
DESCRIPTION
Bit2: 1 = Relay 3 Energized
Bit3: 1 = Relay 4 Energized
Bit4: 1 = Relay 5 Energized
T37
Short
MPS Command
0: Stop
1: Start 1
2: Start 2
3: Reset Trips
4: Set Real-Time Clock
5: Clear Data-Logging Records
6: Clear Trip Counters
7: Not Used
8: Clear Running Hours
9: Emergency Thermal Reset
10: Select Local Control
11: De-select Local Control
12: Re-enable Temperature Protection
13: Start Time
T38
Short
Overload Reset Type
0: Normal
1: Auto Reset
2: Multiple-Motor Sequence
T39
Short
Language
0: English
1: Spanish (Not supported at this time.)
2: French (Not supported at this time.)
T40
Short
Number of OPI’s
0: 1 OPI
1: 2 OPI’s
2: 3 OPI’s
T41
Short
Starter Transfer Type
0: Time Transfer
1: Current Transfer
T42
Short
Trip Action
0: Disabled
1: Trip1
2: Trip2
3: Trip3
4: Trip1 & Trip2
5: Trip1 & Trip3
6: Trip1 & Trip2 & Trip3
7: Trip2 & Trip3
T43
Short
Alarm Action
0: Disabled
1: Alarm1
2: Alarm2
3: Alarm3
4: Alarm1 & Alarm2
