Page B-3
MPS Motor Protection System Rev. 6-F-022117
Appendix B, MPS Set-Up Record
PARAMETER AND SETTINGS
MIN
DEFAULT
MAX
UNIT
PROGRAM SELECTION
RTD-Module-Error Alarm
Action
Disable
q Disable
q Alarm2
q Alarm1
q Alarm3
Temperature Trip Action
Trip1
q Disable
q Trip2
q Trip1
q Trip3
Temperature Alarm Action
Alarm1
q Disable
q Alarm2
q Alarm1
q Alarm3
DIF Module
Enable/Disable
Disable
q Enable
q Disable
DIF-Module-Error Trip Action
Disable
q Disable
q Trip2
q Trip1
q Trip3
DIF-Module-Error Alarm
Action
Disable
q Disable
q Trip2
q Trip1
q Trip3
Network Communications
Network Type
Modbus
q None
q Allen-Bradley
q Modbus
q DeviceNet
q Anybus
q Modbus TCP
Network ID
0
254
255
Baud Rate
SCI 9600
q SCI 1200
q SCI 2400
q SCI 4800
q SCI 9600
q SCI 19200
(1)
q DN125
q DN250
q DN500
Error Checking
Not
Selected
q Not Selected
q CRC
q BCC
Ethernet IP
192.168.
000.001
Ethernet Mask
255.255.
255.000
Default Gateway
0.0.0.0
Network-Error Trip Action
Disable
q Disable
q Trip2
q Trip1
q Trip3
Network-Error Alarm Action
Disable
q Disable
q Alarm2
q Alarm1
q Alarm3
DeviceNet Producing Assembly
0x36
q None
q 0x33
q 0x35
q 0x64
q 0x66
q 0x32
q 0x34
q 0x36
q 0x65
q 0x67
DeviceNet Consuming Assembly
None
q None
q 0x03
q 0x05
q 0x02
q 0x04
System Name
Startco MPS
Change Password
1111
Password Timeout
1
10.00
60
min.
I
p
Threshold
(I
P
is Phase-CT-Primary Rating)
0.10
0.10
0.50
x I
p
Firmware Revision
See Protection | System Config | Maintenance | Firmware Version
Trace Auto-Start
Disable
q Enable
q Disable
(1)
Error rate is 1 byte/120 kB. For high reliability, use SCI9600.
