SCPC System • System description
CP_SEM_60-03-00.002 15
Item Description Function
1 SCPC System
2 Mains power switch ➜ Powering the SCPC System up/down
3 Touchscreen ➜ Operation and configuration of the
SCPC System:
–Pressure control
– Temperature monitor
– Level control
–Bubble detector
– Two independent timers
– Controlling the UPS operation
–Time and date
4 Grip ➜ Transportation of the SCPC System
➜ Mounting of the SCP pump control panel and the
SCP drive unit
5 Ventilation grills ➜ Ventilation of the SCPC System (above the
mains power switch and at the bottom of the
device)
6 Potential equalization point ➜ Connection of the potential equalization cable
7 Mains protection ➜ Automatic circuit breaker 8 A
8 Jack for AC power cable ➜ Power supply of the SCPC System
9 AC power cable
10 Retaining bracket ➜ Securing the AC power cable
11 Jack for connection of the SCP pump
control panel
➜ Connection of the pump control panel to the
SCPC System
12 Jack for connection to the Electrical
Remote-Controlled Tubing Clamp (ERC)
➜ Connection of the ERC to the SCPC System
13 Jack for connection to the serial port ➜ Connection of the Sorin Data Management
System (abbr: Sorin DMS)
14 Sensor module dual pressure ➜ Connection of the sensors for pressure displays
1 and 2
15 Sensor module temperature monitor ➜ Connection of the temperature probes for
temperature monitoring
16 Cover plate ➜ Splash protection
17 Blanking plates ➜ Covering the power module
