SCPC System • Appendix
CP_SEM_60-03-00.002 79
7.5 Part numbers of service components
These part numbers refer to parts and components that are used exclusively for service purposes. The
details on the item numbers relate to the components overview in chapter 3.
7.5.1 Individual SCPC System components
Item Description Number SP number
A 1 Upper casing 60-03-02
A 2 Lower casing
A 3 Housing grip, compl., consisting of:
(1) Screw cap, D 13 mm
(2) Allen bolt, 2 pcs., DIN 912, M6x60
(3) Grip
(4) Mast segment, 2 pcs., L 45mm
(5) Termination plate, 2 pcs.
96-531-015
71-115-055
60-03-35
60-03-36
60-03-37
A 4 Mains switch (voltage-dependent)
220-240 V/1.0 A,
110-127 V/2.0 A
100 V/2.5 A
3120-F321
3120-F321
3120-F321
96-143-006
96-143-007
96-143-008
A 5 Mains filter
220-240 V
100-127 V
FN610A-06/6
FN610-B-10
96-401-011
96-401-013
A 6 Batteries 96-405-003
A 7 Ring core transformer 96-403-058
A 8 Rectifier 93-154-028
A 9 Clamping strip (mains – ring core transformer
connection)
96-204-098
A 10 Discharge resistor (for battery discharge) 97-103-642
A 11 Automatic circuit breaker 8.0 A 96-148-115
A 12 Fan 96-406-003
A 13 SCP System Connections
A 14 Connection for Electrical Remote-Controlled
Tubing Clamp (for short: ERC)
A 15 Serial interface connection
