LivaNova SCPC - Page 19

SCPC System • System description
CP_SEM_60-03-00.002 19
Mod. Item Description Number SP number
A1Upper casing 60-03-02
A2Lower casing
A3Housing grip, compl., consisting of:
(1) Screw cap, D 13 mm
(2) Allen bolt, 2 pcs., DIN 912, M6x60
(3) Grip
(4) Mast segment, 2 pcs., L 45mm
(5) Termination plate, 2 pcs.
96-531-015
71-115-055
60-03-35
60-03-36
60-03-37
A4Mains switch (voltage-dependent)
220-240 V/1.0 A
110-127 V/2.0 A
100 V/2.5 A
3120-F321
3120-F321
3120-F321
96-143-006
96-143-007
96-143-008
(96-143-002
obsolete)
(96-143-004
obsolete)
(96-143-005
obsolete)
A5Mains filter
220-240 V
100-127 V
FN610A-06/6
FN610-B-10
96-401-011
96-401-013
A6Batteries 96-405-003
A7Ring core transformer 96-403-058
A8Rectifier 93-154-028
A9Clamping strip (mains – ring core transformer
connection)
96-204-098
A10Discharge resistor (for battery discharge) 97-103-642
A11Automatic circuit breaker 8.0 A 96-148-115
A12Fan 96-406-003
A13SCP System Connections 97-101-901
A14Connection for Electrical Remote-Controlled
Tubing Clamp (for short: ERC)
A15Serial interface connection
