LivaNova SCPC - Mains Monitoring (ZNU 2003) Circuit Board

SCPC System • System description
CP_SEM_60-03-00.002 27
Mains monitoring (ZNU 2003) circuit board
fig. 10: Overview of battery monitoring (ZAU 2002) circuit board
C 28
C 29
C 30
Mod. Item Description Number SP number
C28Connection for Backplane circuit board CON 1
C29Fuse 10 A, slow-blow (battery) S 1 93-511-030
C301 A miniature fuse, slow-blow S 2 93-510-039
