SCPC System • Appendix
72 CP_SEM_60-03-00.002
7.1.2 Electrical specifications
SCPC System
Drip-proof IPX2
Input voltages 100 V ~, 110 V ~, 115 V ~, 120 V ~ ,
127 V ~, 220 V ~, 230 V ~, 240 V ~ ;
50 / 60 Hz
Power consumption 220 VA
Primary fuse
(also the mains switch)
Automatic circuit breaker
1.0 A nominal trigger current at 230 V
2.0 A nominal trigger current at 120 V
Sensor module: Pressure control
Operating voltages +5 V, ±12 V
Power consumption 3 W
Output voltage to pressure transducer < 10 V
Input resistance 100 Ω
