SCPC System • Appendix
CP_SEM_60-03-00.002 73
UPS
Sensor module: Temperature monitor
Operating voltages +5 V, ±12 V
Power consumption 3 W
Temperature measurement range 0 °C through 50 °C
Resolution 0.1 °C
Accuracy 0.0 °C through 25.0 °C ± 0.2 °C
25.0 °C through 45.0 °C ± 0.1 °C
45.0 °C through 50.0 °C ± 0.2 °C
Sensor module: Level/bubble
Operating voltages +5 V, ±12 V
Power consumption 3 W
Alarm limit (level sensor)
for oxygenators/reservoirs made of rigid
polycarbonate, wall thickness at sensor
position 3 mm max.
Level arrow of sensor holder ±10 mm
(0.4 in.)
Serial port
Baud rate (fixed) 9600
Word length (fixed) 7 bits
Parity (fixed) none
Stop bits (fixed) 1
Polling interval (fixed)
(TX-Data interval from the SCPC System)
10 seconds
Port electrically isolated:
Isolation voltage
Resistance to high voltage
1.5 kV
up to 4 kV
Serial connection cable:
2 x D-SUB 9f
Operating time of UPS
With the SCP System as operational load:
(5.0 LPM at 400 mmHg back pressure)
Minimum: 90 minutes
Charging time 20 hours max.
