SCPC System • Appendix
74 CP_SEM_60-03-00.002
7.1.3 Dimensions and weights of the SCPC trolley
Dimensions and weights
Height (without mast) 165 mm
Depth 609 mm
Width (incl. push grip) 425 mm
Weight approx. 21.5 kg
(incl. two masts and push grip)
A set up overall system must not exceed a
total weight of 61.5 kg.
Maximum admissable load
Maximum load per mast 10 kg
Maximum total load 40 kg
Masts
Telescope mast (movable)
Height (from floor level) 1,250 mm min.
1,800 mm max.
Diameter (fixed part) Ø 33 mm
Diameter (telescope) Ø 25 mm
Maximum load 10 kg (max. mounting height at 1,200 mm
and max. cantilever 200 mm)
Vertical mast
Height (from floor level) 1,200 mm
Diameter Ø 33 mm
Maximum load 10 kg (max. mounting height at 1,200 mm
and max. cantilever 200 mm)
