SCPC System • Replacing components
68 CP_SEM_60-03-00.002
6.9.2 Mains monitoring (ZNU 2002) circuit board
Replacing fuses
fig. 39: Mains monitoring circuit board fuses
!
Only replace the fuses with the fuses of the same type and specifications! Otherwise damage may be
caused to the SCPC System.
Description Number SP number
C 29 10 A fuse slow-blow (battery) S 1 93-511-030
C 30 Miniature fuse 1 A, slow-blow S 2 93-510-039
