LivaNova SCPC - Service Menu Displays Explained

SCPC System • User menu and service menu
34 CP_SEM_60-03-00.002
4.2.2 Displays in the Service menu
fig. 14: Overview of Service menu (page 1)
Charge
Charge Status :
Deep Ch. Time:
Fast I Time:
Fast U Time:
Capactiy:
Info
Stored Offset:
Stored Capactiy:
Low Capactiy:
Discharge Curve Use
Overload Condition
Number of Deep Discharges
Charge time too long
Actual Error Number:
Test in 62 days, last:
Actual Values
Battery Current:
Battery Voltage:
Boost Voltage:
Int. Voltage:
Cooler Temp.:
Power: MS/PD/
Discharge
Charge Status:
Dischr. Time:
Battery Time:
Battery Load:
Capactiy:
Status
AC POWER
ZAU NORMAL OP
TRICKLE CHARGE
28 %
0:24:52 h
1:13:34 h
0:13:34 h
7.025 Ah
-0.057 A
26.746 V
29.412 V
27.754 V
37 C
Change: 07
56 %
0:25:53 h
0:27:23 h
34 %
7.013 Ah
5 mA
7.115 Ah
( )
(possible)
( )
0
( )
7
27.08.02
Accept00125h
=> 0h
I-Probe
Calibr.
Mode
Charge (all details are only updated during the charge process)
Charge Status [%] Charging level
Deep Ch. Time [h] Duration of the 1st battery charge phase
Fast I Time [h] Duration of the 2nd battery charge phase
Fast U Time [h] Duration of the 3rd and last battery charge
phase
Capacity [Ah] Battery capacity
Discharge (all details are only updated during the discharge process)
Charge Status [%] Charge remaining
Dischr. Time [h] Duration of the current discharge process
Battery Time [h] Remaining time for battery operation at
current load
Battery Load [%] Battery load
Capacity [Ah] Battery capacity
