SCPC System • User menu and service menu
CP_SEM_60-03-00.002 31
Item Description Function
M34Main menu ➜ Display of all set parameters and
measured values
(in this case for the configuration:
“Pressure + flow” and “1 temperature
channel + level/bubble”)
➜ Go to
–Pressure menu
– Temperature menu
– Level/bubble menu
– Pumps menu
M35Pressure menu ➜ Input limit values
M36Temperature menu ➜ Input limit values
M37Level/bubble menu ➜ Switching the audio alarm on and off
for level or bubble alarm
M38Pumps menu 1
M39Pumps menu 2
M40Pumps menu 3
➜ Entering the alarm limit values for
pump flow and speed of the
SCP System
➜ Zero compensation of the flow sensor
➜ Display of the hours of operation of
the SCP System
➜ Register the Electrical Remote-
Controlled Tubing Clamp (ERC)
