13A-3
FUEL SUPPLY
Injector rail - Injectors
K7J, and 710
13A
Remove:
-the rail mounting bolts.
-the injection rail.
Remove:
-clips (5),
-the injectors.
REFITTING
Replace the O rings at the base of the injector (if the
injector has been removed, also replace the seal
which is level with the injector head).
Check for the « click » of the fuel unions when con-
necting.
Torque tighten the injection rail mounting bolts
(0.7 daNm).
Proceed in the reverse order to removal.
IMPORTANT
During this operation, it is essential to:
-refrain from smoking or bringing incandescent
objects close to the work area,
-beware of fuel splashes when disconnecting the
union,
-protect sensitive areas from fuel outflow.
101473
5
WARNING
Connect the battery, starting with the positive ter-
minal; carry out the necessary programming (see
80A, Battery, Battery: Remove and Refit).
