16A-10
STARTING - LOAD
Alternator
K7M, and 710, and DIRECTION ASSISTEE, and AIR CONDITIONING
16A
REMOVAL
Remove:
-the front bumper (see 55A, Exterior protection,
Front bumper),
-the accessories belt (see 11A, Top and front of
engine, Accessories belt).
Disconnect power assisted steering pressostat con-
nector (1).
Remove:
- power assisted steering pump mounting bolt (2),
- power assisted steering pump mounting bolts (3)
by pulling them through the holes in the pulley,
- the power assisted steering pump from the multi-
function support (without opening the circuit).
Place the power assisted steering pump to one side.
Tightening torquesm
alternator mounting
bolts
2.1 daNm
air conditioning com-
pressor mounting bolts
2.1 daNm
power assisted steering
pump mounting bolts
2.1 daNm
109397
108930
2
1
3
