16A-15
STARTING - LOAD
Starter motor
K7M, and 710
16A
REMOVAL
Mount the vehicle on a lift.
Disconnect the battery, starting with the negative ter-
minal.
Remove:
-the computer cover by unclipping it in the direction
of (1),
-the expansion bottle mounting bolts,
-the expansion bottle (without opening the circuit),
Place the expansion bottle to one side.
Remove gearbox control linkage mounting bolt (2).
Tightening torquesm
starter mounting bolts 4.4 daNm
107847
11
109214
WARNING
The linkage is fitted with a spacer; do not lose the
spacer when removing bolt (2).
2
