19C-9
RESERVOIR
Pump / sender unit / filter
K7J or K7M, and 710
19C
REFITTING
It is essential to replace O-ring (1).
Refit the pump/gauge/filter assembly.
Tighten the locking ring on the pump/gauge/filter as-
sembly using tool (Mot. 1397).
Proceed in the reverse order to removal.
109180
WARNING
Make sure that the seal is positioned correctly
when the pump/gauge/filter assembly is refitted.
1
109179
WARNING
The pump/gauge/filter assembly index and loc-
king ring index must be between the two mar-
kings on either side of the fuel tank index.
WARNING
Connect the battery, starting with the positive ter-
minal; carry out the necessary programming (see
80A, Battery, Battery: Remove and Refit).
