10A-34
ENGINE AND LOWER ENGINE ASSEMBLY
Sump
L90, and K7J, and 710
10A
Apply:
-four beads (5) of RHODORSEAL 56615 mm in dia-
meter,
-two spots (6) of RHODORSEAL 5661 of a diameter
of 7 mm at the intersection of the crankshaft closing
panel and the cylinder block.
20166
20167
Note:
The gasket faces must be clean, dry and free
from grease (avoid finger marks).
6
5
5
Note:
Excess sealant could be squeezed out when the
parts are tightened. The sealing compound/fluid
mixture can cause damage to certain compo-
nents (engine, radiator, etc.).
