Lonking CDM853 - 2.2 OUTLINE DRAWING OF WHEEL LOADER

62
ITEM
ITEM
ITEM
ITEM
CDM85 3
Steering
System
Type
Fully hydraulic load-sensitive
Number of steering cylinders — inner diameter ×
stroke (mm)
2- φ 90 X324mm
Steering pump
Gear pump with constant displacement
System working pressure (MPa)
1 5
Steering angle ( ° )
Left/ right 35
Working mechanism
Number of boom cylinders – inner diameter × stroke
(mm)
2- φ 1 60 × 836 mm
Number of bucket cylinders – inner diameter ×
stroke(mm)
1- φ 180 × 5 59 mm
Distribution valve
Hydraulically-controlled, multi-way valve
Model number
D32.2
Displacement of working pump (ml/r)
220/2200
System working pressure (MPa)
16
Working device
Single-rocking-arm, reverse six-link
mechanism
Electrical system
System voltage (V)
24
Battery capacity (Ah)
2-N1 20
Lamp voltage (V)
24
Diesel engine starting
24V electric starting
Filling capacity
Total volume of hydraulic oil tank and fuel tank
285L
Hydraulic oil filling amount
270L
Engine oil filling amount
20L
Oil filling amount of gearbox
4 5 L
Total oil filling amount of front & axle drive axles
28L/28 L
Air conditioning system
Warm air
Operating medium
Diesel coolant
Heating power
5 0 00 W ± 10%
Cool air
Operating medium
R134a
Refrigerating power
4 2 00 W ± 10%
System voltage (V)
24
Note:
1. Technical parameters involved in this instruction book are not inspection or test bases. Those
parameters may be changed without notice.
2. The foregoing oil filling standards are for reference only. Oil replenishment is performed depending on
actual liquid level of oil inspected.
