3.15
3.15
3.15
3.15 ADJUSTMENT
ADJUSTMENT
ADJUSTMENT
ADJUSTMENT TO
TO
TO
TO REAR-VIEW
REAR-VIEW
REAR-VIEW
REAR-VIEW MIRROR
MIRROR
MIRROR
MIRROR
A
rear-view mirror is installed on the left and right front of Cab top, respectively. Adjust the
rear-view mirrors to correct positions before operating the loader.
To
adjust the position of rear-view mirror, loosen the bolt that fastens the rear-view mirror
support to the Cab, and then rotate the support. Loosen the connection bolt between rear-
view mirror and support, rotate rear-view mirror to the right position. Then tighten the bolt.
3.16
3.16
3.16
3.16 TURNING
TURNING
TURNING
TURNING LAMPS
LAMPS
LAMPS
LAMPS AND
AND
AND
AND FULL-BEAM/LOW-BEAM
FULL-BEAM/LOW-BEAM
FULL-BEAM/LOW-BEAM
FULL-BEAM/LOW-BEAM
HEADLIGHTS
HEADLIGHTS
HEADLIGHTS
HEADLIGHTS
The loader has the control switches for turning lamps and full-beam/low-beam headlights.
They are located below the right side of cab steering wheel.
3.17
3.17
3.17
3.17 CHARGING
CHARGING
CHARGING
CHARGING DOCK
DOCK
DOCK
DOCK
Turning lamp and full-beam/low-beam headlight
switches
1. Turning lamp switch
This switch is used to turn on and off turning
lamps when the loader turns.
2. Full-beam/low-beam headlight switch
Rotating control handle is used to turn on and off
full-beam and low-beam headlights.
Reserved for charging of cigarette lighter and
mobile phone.
(Figure 1) 12V 100W
(Figure 2) 24V 120W
