PyroTec™ PRO Hardw are User’s Manual, V1.2 31
RT-MN024-1.2 02/21
Air LiHa
Operating
Ranges
Axis
LiHa type
PyroTec™ PRO
X-axis
All
Refer to section on Worktable
Access Range
Y-axis
8-tip LiHa
373 mm (14.7 in.)
Z-axis
All
210 mm (8.27 in.)
Clearance
The tip clearance is the maximum space between the worktable surface and the mounted
tip (initial position).
Tip type
Tip clearance
DiTi adapter (A)
260 mm (10.24 in.)
Reference tip (B)
210 mm (8.27 in.)
DiTi 1000 µl (C)
178 (7.01 in.)
Air LiHa
Accuracy/
Precision
The positioning accuracy of the Air LiHa allows for the following applications:
• Air LiHa can be used in combination with 96-well microplates.
Axis
Repeatability
X
±0.15 mm (0.006 in.)
Y
±0.15 mm (0.006 in.)
Z
±0.3 mm (0.012 in.)
Equidistant Tip
Movement
The equidistant movement of sampling tips in Y direction is:
• from 9 mm ± 0.4 mm
• to 38 mm ± 1 mm
Disposable
Tips
Use only Lonza disposable tips. Conductive disposable tips are available with filter, in fol-
lowing volumes:
• 1000 µl
DiTi Carrier
A DiTi Carrier holds up to three trays of 96 disposable tips.
Air LiHa Tip Adapter
The Air LiHa is equipped with a special type of tip adapters, which contain a pressure sen-
sor, the electronics for the Air LiHa MultiSense functions and a user replaceable Inline fil-
ter.
