To lift the instrument, the transport handles must be applied to the base structure of the
instrument. Consider the safety instructions above.
To apply the transport device, proceed as follows:
• Attach all four transport handles
• Shift bars through the handles
• Secure the bars with the pins
7.2 Storage
Protect the instrument against dust and debris with a cover. For long-term storage, pack
the instrument in its original packing.
7.3 Packaging
dimensions
The figure shows the packaging of the PyroTec™ PRO:
Approx. 61.4 in
Approx. 36.2 in
Approx. 49 in
Approx. 551
