4.4 System Modules
The system modules are briefly introduced in the following sections. According to your or-
der configuration, some of these options might be installed.
4.4.1 Air Displacement Pipetting Arm (Air LiHa)
The PyroTec™ PRO is equipped with an Air LiHa which is a robotic arm having multiple pi-
pette tip for general pipetting tasks. The Air LiHa working principle is based on air displace-
ment technology where a Plunger Drive, directly mounted on top of a pipetting channel,
varies the volume of an air chamber for aspiration and dispensing. The Air LiHa is designed
for use with disposable tips only.
General Data
Usable tips
Disposable tips
• Conductive
• With filter
1000 µl
Number of channels
8
Tip spreading
Distance from tip to tip
9 to 38 mm (0.31 to 1.5 in.)
Volume range
0.5 µl to 1000 µl (1 ml)
Theoretical resolution
0.1 µl
Dispense speed
1000 µl
less than 2 seconds
Dispense modes
0.5 µl to max. volume
Free (non-contact) dispense for
single pipetting or contact dis-
pense
5 µl to max. volume
Free (non-contact) dispense for
multi pipetting
DiTi pickup force
23 N +/- 4 N
Pipetting Precision
Refer to the tables in Air LiHa Pipetting Precision below.
Special functions
Liquid level detection
pLLD and PMP
Lower DiTi eject
See corresponding sections with
the same names.
