Geräteelemente
- 4 - 10.13
1 Geräteelemente
4
0
0
V
2
3
0
V
400 V
230 V
3
4
5
2
6 87 9 2
10
11
1
Abb. 1: Geräteelemente
1 Sicherungskette
2 Verlastungspunkte
3 Netzkabel
4 Netzspannungsumschalter (bei um-
schaltbaren Geräten)
5 Schutzgasschlauch
6 Ablageäche
7 Handgriff
8 Bedienfeld
9 Hauptschalter
10 Anschlussbuchse für Werkstückleitung
11 Zentralbuchse
Abgebildetes oder beschriebenes
Zubehör gehört teilweise nicht
zum Lieferumfang. Änderungen
vorbehalten.
i
