Messages
- 50 - 10.13
13.7 Special functions
Gas test
 Turn the unit OFF using main switch 9.
 Press the torch key and keep it pressed.
 Turn the unit ON using main switch 9.
9 The solenoid valve of the unit will go on
and the gas supply can be tested/adjust-
ed. The function is active for 30 seconds
and will be automatically stopped. Re-
pressing the torch key. can interrupt the
gas test.
Fan test
 Turn the unit ON using main switch 9.
9 The fan will start for function purposes.
Operation panel test
 Press the mode key 60 for at least 5 sec-
onds.
9 All operation displays will ash for approx.
20 seconds.
13.8 Reset setting
Master reset
Attention All personal settings
will be lost.
All welding and secondary param-
eters are reset to their factory set-
tings.
 Turn the unit OFF using main switch 9.
 Press the mode key 60 and keep it
pressed.
 Turn the unit ON using main switch 9.
9 All symbols and displays will light up
shortly to conrm reset.
During operational faults/malfunction , the
7-segment display 47 displays an error
code.
As long as there is an error code
on display welding is not possible.
14 Messages
Code Error description Note Rectication
E00 no program Selected programme number does
not exist.
Select a different char-
acteristic line
Instead of material thickness „--- "
is displayed and by pressing the
torch key „E00" shows up. Welding
is not possible at activated charac-
teristic line and set welding step.
Select a different weld-
ing step
E01 Excessive tempera-
ture
The equipment has been over-
heated
Allow the system to cool
down in standby, check
the ventilation system
