116
Appendix K: Full Connectivity Diagram
Appendix K: Full Connectivity Diagram
The following diagram outlines a general set of connections available with the system*.
*8-channel model shown.
EXTERNAL MONITORS
(Not Included)
POWER
PTZ CAMERA
(Not Included)
BNC CAMERAS
VGA MONITOR
(Not Included)
AUDIO CAPABLE
CAMERA
(Not Included)
(Not Included)
SELF
POWERED
SPEAKERS
USB MEMORY KEY
(Not Included)
USB MOUSE
Router
(Not Included)
(Not Included)
4/8 Channel Model
