Lorex LH114000 Series User Manual

12
Mouse Control
Mouse Control
The system is designed for mouse navigation. To use the mouse, connect the mouse to the
rear USB panel on the DVR.
1 Use the
mouse buttons to perform the following:
• Left-Button:
Click to select a menu option;
d u r i n g l i v e v i e w i n g i n s p lit-screen, double-click
on a channel to view the selected channel in
full-screen.; double-click the channel again to
return to split-screen view
2 Right-B
utton:
• Click to open the Sub-Menu (see “Using the
Sub-Menu”
on page 18.).
• In menus, use the right-button to exit menus.
3 Scroll-Wheel: N
o function.
*8-channel model shown
4/8 Channel Model
Plug the mouse into the top USB port.
Plug the mouse into the top USB port
16 Channel Model
1 2
3
