Chapter 9. Installation and Wiring
9-12
(6) Distance with other device
To avoid radiation noise or heat, keep the distance between PLC and device (connector and relay) as far as the
following figure.
Device installed in front of PLC: 100 ㎜ or above
Device installed beside PLC: 50 ㎜ or above
100mm or above
50mm or above
50mm or above
