Chapter 2. System Configuration
2-2
XGB series’ product list is as follows.
Types Model Description Remark
Main Unit
XEC-DR32H AC 100V~220V power, DC24V input 16 points, relay output 16 points
-
XEC-DN32H AC 100V~220V power, DC24V input 16 points, TR output 16 points
-
XEC-DN32H/DC DC 24V power, DC24V input 16 points, TR output 16 points
XEC-DR64H AC 100V~220V power, DC24V input 32 points, relay output 32 points
-
XEC-DN64H AC 100V~220V power, DC24V input 32 points, TR output 32 points
-
XEC-DR32H/D1 DC 12/24V power, DC12V input 16 points, relay output 16 points
XEC-DR64H/D1 DC 12/24V power, DC12V input 32 points, relay output 32 points
Digital I/O module
XBE-DC08A DC24V Input 8 point
XBE-DC16A DC24V Input 16 point
XBE-DC32A DC24V Input 32 point
XBE-RY08A Relay output 8 point
XBE-RY08B Relay output 8 point (independent point)
XBE-RY16A Relay output 16 point
XBE-TN08A Transistor output 8 point (sink type)
XBE-TN16A Transistor output 16 point (sink type)
XBE-TN32A Transistor output 32 point (sink type)
-
XBE-TP08A Transistor output 8 point (source type)
XBE-TP16A Transistor output 16 point (source type)
XBE-TP32A Transistor output 32 point (source type)
-
XBE-DR16A DC24V Input 8 point, Relay output 8 point
XBE-DN32A DC24V Input 16 point, Transistor output 16 point (sink type)
Special Module
XBF-AD04A Current/Voltage input 4 channel
Analog
ln/Out
XBF-AD04C Current/Voltage input 4 channel, High resolution
XBF-AD08A Current/Voltage input 8 channel
XBF-DC04A Current output 4 channel
XBF-DC04C Current output 4 channel, High resolution
XBF-DV04A Voltage output 4 channel
XBF-DV04C Voltage output 4 channel, High resolution
XBF-AH04A Current/Voltage input 2 channel, Current/Voltage output 2 channel,
XBF-RD04A RTD (Resistance Temperature Detector) input 4 channel
Temperat
ure
XBF-RD01A RTD (Resistance Temperature Detector) input 1 channel
XBF-TC04S TC (Thermocouple) input 4 channel
XBF-PD02A Position 2Axis, Line Drive type Position
XBF-HD02A High Speed Counter 2 channel, Line Drive Type Counter
