LSIS XEC-DR64H User Manual

Chapter 4. CPU Specifications
4-1
Chapter 4 CPU Specifications
4.1 Performance Specifications
The following table shows the general specifications of the XGB main module type
Items
Specifications
Remark
XEC-
DR32H(/D1)
XEC-
DR64H(/D1)
XEC-
DN32H(/DC)
XEC-
DN64H
XEC-
DP32H
XEC-
DP64H
Numb
er of
instruc
tions
Operator
18
Basic function
136 + Real number operation function
Basic function block
43
Dedicated function
block
Special function dedicated function
Processing speed
Basic instruction : 0.083
㎲
/step
Program memory capacity 200KB (XEC 200KB corresponds to XGI 110KB)
Max. I/O points
352
384
352
384
352
384
Data
memory
Automatic variable
(A)
32KB (Max. 16KB retain setting available)
Input variable (I)
2 KB (%IX15.15.63)
Output variable (Q)
2 KB (%QX15.15.63)
Direct
variable
M
16KB (Max. 8KB retain setting available)
R
20KB (1block)
W
20KB
Same area with R
Flag
variable
F 2KB System flag
K
8KB
Built-in special flag
L
4KB
High speed link flag
N 10KB P2P flag
U
1KB
Analog flag
Flash area
20KB, 2 block
R device used
Timer No limit to the number of point (time range: 0.001s ~ 4,294,967,295s)
20 byte automatic
variable area
occupied per r point
Counter No limit to the number of point (count range: 64 bit expression range)
Operation mode
RUN, STOP, DEBUG
Restart mode
Cold, Warm
Total number of program
block
128
Task
Initialization
1
Fixed period
8
External input
8 (%IX0.0.0 ~ %IX0.0.7)
Internal device
8
Self diagnosis
Detecting operation delay, memory error, I/O error
Data reserved in case of
power cut
Setting retain area at basic parameter
Number of max. extension
stage
10 stage
Internal consumption
current
660mA 1,040mA 260mA 330mA 300mA 380mA
Weight
600g
900g
500g
800g
500g
800g
