Chapter 6. CPU Function
6-6
CPU module may change operation by communication as well as by key switches mounted on the module. To
operate it remotely, it is necessary to set ‘RUN/STOP’ switch to ‘STOP’.
(1) Remote operations are as follows.
(a) Operable by accessing to XG5000 through RS-232C port mounted on CPU module.
(b) Can operate other PLC connected to PLC network with CPU module connected to XG5000.
(2) Remote RUN/STOP
(a) Remote RUN/STOP is the externally controlled RUN/STOP function.
(b) It is convenient when CPU module is located at a position hard to control or when CPU module within
control panel is to control RUN/STOP function remotely.
(3) Remote DEBUG
(a) it manages debugging remotely when remote mode is STOP. Namely, DEBUG operation is to execute
program operation depending on designated operation conditions.
(b) Remote DEBUG is a convenient function when confirming program operation status or data during system
debugging.
(4) Remote Reset
(a) Remote reset is to reset CPU module remotely if an error occurs at a place hard to directly control CPU
module.
(b) Like operation by switches, it supports ‘Reset’ and ‘Overall Reset’.
Remark
For details regarding remote functions, refer to ‘Online’ of XG5000 Users Manual.
