Appendix 1.3 Network Register (N) List
Here describes Network Register for communication (N). P2P parameter: 1~3, P2P block: 0~31
Device Keyword Type Description
%NW000 _P1B00SN Word Saves another station no. of P2P parameter 1, 00 block.
%NW0000~0004 _P1B00RD1 Word Saves area device 1 to read P2P parameter 1, 01 block.
%NW005 _P1B00RS1 Word Saves area size 1 to read P2P parameter 1, 01 block.
%NW0006~0009 _P1B00RD2 Word Saves area device 2 to read P2P parameter 1, 01 block.
%NW010 _P1B00RS2 Word Saves area size 2 to read P2P parameter 1, 01 block.
%NW0011~0014 _P1B00RD3 Word Saves area device 3 to read P2P parameter 1, 01 block.
%NW015 _P1B00RS3 Word Saves area size 3 to read P2P parameter 1, 01 block.
%NW0016~0019 _P1B00RD4 Word Saves area device 4 to read P2P parameter 1, 01 block.
%NW020 _P1B00RS4 Word Saves area size 4 to read P2P parameter 1, 01 block.
%NW0021~0024 _P1B00WD1 Word Saves area device 1 to save P2P parameter 1, 01 block.
%NW025 _P1B00WS1 Word Saves area size 1 to save P2P parameter 1, 01 block.
%NW0026~0029 _P1B00WD2 Word Saves area device 2 to save P2P parameter 1, 01 block.
%NW030 _P1B00WS2 Word Saves area size 2 to save P2P parameter 1, 01 block.
%NW0031~0034 _P1B00WD3 Word Saves area device 3 to save P2P parameter 1, 01 block.
%NW035 _P1B00WS3 Word Saves area size 3 to save P2P parameter 1, 01 block.
%NW0036~0039 _P1B00WD4 Word Saves area device 4 to save P2P parameter 1, 01 block.
%NW040 _P1B00WS4 Word Saves area size 4 to save P2P parameter 1, 01 block.
%NW0041~0081 - Word Saving area of P2P parameter 1, 01 block.
%NW0082~0122 - Word Saving area of P2P parameter 1, 02 block. P2P
%NW0123~1311 - Word Saving area of P2P parameter 1, 03~31 block.
%NW1312~2623 - Word Saving area of P2P parameter 2.
%NW2624~3935 - Word Saving area of P2P parameter 3.
Remark
 In XGB series, Network register is available only monitoring. (Read Only)
