LSIS XEC-DR64H User Manual

Chapter 4. CPU Specifications
4-4
4.3 Power Supply Specifications
Describes power specification of main unit
Items
Specification
XEC-DR32H
XEC-DN32H
XEC-DP32H
XEC-DR64H
XEC-DN64H
XEC-DP64H
XEC-
DN32H/DC
XEC-
DR32H/D1
XEC-
DR64H/D1
Input
Rated voltage
(UL warranty voltage)
AC 100 ~ 240 V DC24V DC 12/24V
Input voltage range
AC85~264V(-15%, +10%)
DC19.2~28.8V
(-20%,+20%)
DC 9.5~30V
Inrush current 50APeak or less
50APeak
or less
50APeak or less
Input current
AC 220V : 0.5A or less,
AC 110V : 1A or less
0.7A or less
DC 12V :
1.4 A or
less
DC 24V :
0.7 A or
less
DC 12V :
2.1 A or
less
DC 24V :
1.0 A or
less
Efficiency
65% or more
60% or more
Permitted momentary
power failure
Less than 10 ㎳
DC 12V : less than 2
㎳
DC 24V : less than 10
㎳
Output
Rated
output
DC5V
2A
3A
2A
2A
3A
DC24V
0.4A
0.6A
-
-
-
Output voltage ripple
DC5V (±2%) DC4.9~5.15V
Power supply status indication
LED On when power supply is normal
Cable specification
0.75 ~ 2 mm
2
* Use the power supply which has 4 A or more fuse for protecting power supply.

LSIS XEC-DR64H Specifications

General

Brand	LSIS
Model	XEC-DR64H
Category	Controller
Language	English
