Appendix 1. Flag List
A1-
(2) High-speed Link2
Device Keyword Type Description
%LX416 _HS2_RLINK Bit
High-speed link parameter 2 normal operation of all station.
Indicates normal operation of all station according to parameter set in High-
speed link and On under the condition as below.
1. In case that all station set in parameter is Run mode and no error
2. All data block set in parameter is communicated and
3.The parameter set in each station itself is communicated normally.
Once RUN_LINK is On, it keeps On unless stopped by LINK_DISABLE.
%LX417 _HS2_LTRBL Bit
Abnormal state after _HS2RLINK On.
In the state of _HSmRLINK flag On, if communication state of the station set in
the parameter and data block is as follows, this flag shall be On.
1. In case that the station set in the parameter is not RUN mode, or
2. There is an error in the station set in the parameter, or
3. The communication state of data block set in the parameter is not good.
LINK TROUBLE shall be On if the above 1, 2 & 3 conditions occur, and if the
condition return to the normal state, it shall be OFF again.
Bit
Array
Indicates total status of High Speed Link no.1 ***th block
Indicates total status of communication information about each data block of
parameter
_HS2_STATE*** = HS2MOD***&_HS2TRX***&(~_HS2_ERR***)
Bit
Array
RUN operation mode of High Speed Link parameter no.1 ***th block station
Indicates operation mode of station set in *** data block of parameter
000~063)
Bit
Array
Indicates normal communication with High Speed Link no.1 ***th block station
Indicates whether communication status of *** data block of parameter is
normal or not.
Bit
Array
Operation error mode of High Speed Link parameter no.1 ***th block station
Indicates whether there is error at communication status of *** data block of
parameter
Bit
Array
Indicates High Speed Link parameter no.1 ***th block setting
Indicates whether *** data block of parameter is set or not.
