Chapter 4. CPU Specifications
4-7
(3) XGB PLC configuration example 3
Type Model Unit No.
consumption
current
㎃
Remark
Main unit XEC-DR64H 1 1,040
In case of all contact points are
On.
(Maximum consumption current)
Expansion
module
XBE-DR16A 5 250
XBE-TN32A 2 80
XBF-AD04A 1 120
All channel is used.
(Maximum consumption current)
XBL-C21A 1 120
2,690mA -
13.45W
2.69A ⅹ 5V = 13.45W
The above system is an example using XEC-DR64H, 64 points main unit, about system (2). Unlike (2) example,
5V output capacity of XEC-DR64H is maximum 3A, normal configuration is available.
Remark
Calculating of consumption current is based on maximum consumption current. In application system,
the consumption current is consumed less than above calculation.
