Pressing the “PAGE” key from within a menu will return the unit to the menu’s
header, subsequent presses of the “PAGE” key will advance to the next menu.
When the last menu is reached the unit will return to the normal display mode.
Using the “PAGE” and “ENTER” keys simultaneously will allow the unit to move
backwards through the menus.
N.B. When in the menu structure, if none of the buttons are pressed within 2
minutes, the unit will timeout and return to the main display. The Access
Code display will be reset to 0000 30 seconds after returning to the main
display.
There are two levels of access to the menu structure (refer to the menu structure
printed inside the back cover). The first level allows access to the basic setup
operations. The more complex level two menus will only appear when the level
two access code has been entered. Once the access code has been entered
correctly the operator can use the “UP” and “DOWN” keys to select and modify the
access codes.
000
000000
0000
00
0
Access Code ?
Access Code Entry
Ø
ØØ
Ø ×
××
×
0001
00010001
0001
Edit Level 1
Level 1 Code Edit. Press “ENTER” to edit.
(Available when level 1 code has been entered)
Ø
ØØ
Ø ×
××
×
0002
00020002
0002
Edit Level 2
Level 2 Code Edit. Press “ENTER” to edit.
(Available when level 2 code has been entered)
Ø
ØØ
Ø ×
××
×
To Next Page
