Figure 6–2. Menu Selection Screen
Data Entry Screens 6
A data entry screen prompts you to enter specific data or to make specific
choices. If data is currently programmed for the feature, it appears on the screen.
Many screens also show data entered on a previous screen, such as an extension
or trunk number.
Data entry screens may also contain menu selections. Instead of entering data
from the dialpad, you select options on the screen, such as
<HV or 1R, to enable or
disable a feature. To select this type of option, you press the unlabeled display
button next to the option name or the function key that corresponds to the option
name. Then your selection is either highlighted or inserted in the screen title. To
program or save the highlighted selection, you either press the unlabeled display
button on the console next to
(QWHU or press
on the PC. You can use the
Inspect feature to view, verify, or check the entries you save: press the Inspct
fixed display button on the console, or press
on the PC. After you have
finished inspecting the entries, you can return to the previous screen by pressing
the unlabeled display button next to
([LW or by pressing
on the PC. See
System Programming
for more information about the Inspect feature.
Figure 6–3
shows a data entry screen with the first (of two) required extension
numbers needed to assign analog voice and data.
Figure 6–3. Data Entry Screen
6\VWHP3URJUDPPLQJ!
Screen title and More indicator (!)
0DNHD6HOHFWLRQ
Prompt
6\VWHP ([WHQVLRQV
Options
6\V5HQXPEHU 2SWLRQV
2SHUDWRU 7DEOHV
/LQHV7UXQNV $X[(TXLS
([LW 1LJKW6UYFH
'DWD9RLFH'DWD!
Selected Option
(QWHUYRLFHGDWDSDLU
Prompt
Extension entered
'HOHWH
%DFNVSDFH
([LW (QWHU
To Next Page
