DRIVE SYSTEM
Belt Guard Removal and
Installation
WARNING
NEVER operate engine:
– without shields and belt guard
securely installed
– with hood and/or side panels
opened or removed.
NEVER attempt to make adjust-
ments to moving parts while en-
gine is running.
NOTE: Belt guard is purposely m ade
slightly oversize to maintain tension on
its pins an d retainers preventin g un-
due noise and vibration. It is im portant
that this tension be maintained when
reinstalling.
Remove the tether cord c ap (DES S
key).
Open engine compartment LH side
panel.
Remove retaining pin.
mmo2008-003-063_a
1. Retaining pin
Lift rear portion of guard then release
from front tabs.
When reinstalling belt g uard, position
its cutaway toward front of snowm o-
bile.
Place belt guard slots over tabs first,
then snap the other end in rear retain-
er.
mmo2007-009-026_a
TYPICAL
1. Slots
Secure belt g ua rd using retaining pin .
mmo2008-003-063_a
1. Re taining pin
Brake Fluid Level
CAUTION: Vehiclemustbeonalev-
el surface before checking any fluid
levels.
Checkbrakefluid(DOT4)inreservoir
for proper level. Add fluid (DOT 4) as
required.
CAUTION: Use only DOT 4 brake
fluid from a sealed container. Nev-
er use any other types of fluid.
102
