Rear
REAR
1. Grab handle/bumper
CAUTION: Do not use skis to pull or
lift snowmobile.
23) Storage Compartment
WARNING
All storage compartments mus t be
properly latched and they must not
contain any sharp, heavy or break-
able objects.
CAUTION: MAXIMUM load is 1.8 kg
(4 lb) evenly distributed.
Pull latch slightly upward then, back-
ward to unlock cover.
Storage compartment
1. Storage compartment
24) Tool Kit
A tool kit containing tools for basic
maintenance is s u pplied with the ve-
hicle.
Tool bag is located in engine compart-
ment on pulley guard.
Tool kit
1. Tool kit
25) Spark Plug Storage
A space is provided in the tool kit to
keep spare spark plugs dry and pre-
vent shocks that might affect the ad-
justment or break them.
NOTE: Spare spark plugs are not sup-
plied with snowmobile .
NOTE: Check spare spark plug gap ac-
cording to SPECIFICATIONS before in-
stallation.
CAUTION: Do not attempt to adjust
spark plu g gap.
26) Spare Drive Belt Holder
A spare drive belt can be stored in
holder.
NOTE: Spare drive belt is not supplied
with the snowmobile.
CAUTION: To avoid damages to the
drive belt, ensure that belt does not
come in contact with tuned pipe
when installed in its support.
