Lynx RaveTM RE 600 E-TEC - Speedometer; Tachometer (RPM); Gauge Digital Display

1) Speedometer
Measures vehicle speed in miles or
kilometers.
The speedometer is factory preset
in Me tric units but it is po ssib le to
change it to Imperial units, contact an
authorized LYNX dealer for unit set-
tings.
mmo2008-003-014
LH PORTION OF GAUGE
2) Tachometer (RPM)
Measures engine revolution per
minute (RPM). M ultiply by 1000 to
obtain the actual revolutions.
mmo2008-003-019
RH PORTION OF GAUGE
3) Gauge Digital Display
Digital display that supplies several re-
al time useful informatio n to the driver.

WARNING
Reading the gauge digital display
can distract from the operation of
the vehicle, particularly from con-
stantly scanning the environment.
This could lead to a collision result-
ing in severe injuries or death. Be-
fore reading the gauge digital dis-
play, ensure your environment is
clear and free from obstacle, and
bring the vehicle to a low speed.
Before proceeding with any adjust-
ments , park vehicle in a safe p lace
and away from the trail.
The digital display is factory preset
in Metric units but it is p ossible t o
change it to Imperial units, contact an
authorized LYNX dealer for unit set-
tings.
mmo2008-003-013_b
ANALOG/DIGITAL GAUGE
1. Digital display
DISPLAY FEATURES
FUNCTIONS
REFER TO
TOPICS
Odometer
A)
Trip meter “A” or “B” B)
Trip hour meter
C)
Fuel level D)
A) Odometer
Records the total distance travelled.
Push the SET (S) button to select
odometer (Km/Mi) mode.
34
