WARNING
If fuse has burnt out, source of
malfunction should be determined
and corrected before restarting.
See an authorized LYNX dealer for
servicing.
593SS and 800R Engines
Manual Start
mmo2007-009-017_b
RH SIDE OF ENGINE COMPARTMENT
1. Fuse location
Electric Start
mmo2008-003-033_a
RH SIDE OF ENGINE COMPARTMENT
1. Fuse location
2. Battery
Electric Fuel Level Sender
mmo2007-009-016_b
BEHIND AIR INTAKE SILENCER
1. Fuse location
22) G rab Handle/Bumper
To be used whenever snowmobile re-
quires manual lifting.
WARNING
Do not attempt to lift the vehicle
by hand alone. Use appropriate
lifting device or have assistance
to share lifting stress in order to
avoidriskofstraininjuries.
mmo2008-003-016_a
FRONT
1. G rab handle/bumper
